LEUZE DCR 202i FIX-M1-102-R3

LEUZE DCR 202i FIX-M1-102-R3 Product Details

The LEUZE DCR 202i FIX-M1-102-R3 is a compact, stationary 2D code reader designed for reliable identification of 1D and 2D codes. Its small size and easy configuration allow for quick integration into various applications.

Product Parameters

Here are some key technical parameters of the DCR 202i FIX-M1-102-R3:

• Series: DCR 200i

• Technology: Camera-based, CMOS (Global Shutter)

• Readable Codes: 1D and 2D codes including 2/5 Interleaved, Aztec, Codabar, Code 32, Code 39, Code 93, Code 128, Data Matrix Code, EAN 8/13, EAN 128, GS1 Databar, GS1 Databar Omnidirectional, GS1 Databar QR code, GS1 Databar Stacked, PDF417, Pharma Code, QR code, UPC.

• Reading Distance: 50 ... 220 mm

• Light Source: LED, Red

• Camera Resolution: 1280 x 960 pixels (horizontal x vertical)

• Modulus Size: 0.19 ... 0.5 mm

• Interfaces: Ethernet, RS 232, RS 422

• Supply Voltage: 18 ... 30 V DC

• Power Consumption: 8 W (average)

• Digital Inputs: 1

• Digital Outputs: 1

• Housing Material: Metal and Plastic (Diecast aluminum and PC)

• Lens Cover Material: Plastic

• Protection Class: IP 65

• Ambient Temperature (Operation): 0 ... 50 °C

• Ambient Temperature (Storage): -20 ... 70 °C

• Dimensions (W x H x L): 43 mm x 61 mm x 44 mm

• Weight: 120 g

Product Advantages

The LEUZE DCR 202i FIX-M1-102-R3 offers several advantages:

• Compact Design: Its small form factor allows for installation in tight spaces.

• High Reading Performance: Reliable reading of various 1D and 2D codes, even if partially damaged.

• Easy Commissioning: Configuration is intuitive via a web-based tool with a setup wizard or directly on the device. Configuration via smartphone app using configuration codes is also possible.

• Versatile Interfaces: Supports common industrial interfaces like Ethernet, RS 232, and RS 422 for flexible integration.

• Wide Range of Readable Codes: Can read a comprehensive list of 1D and 2D symbologies.

• Adjustable Optics: Different optics models are available for varying reading ranges and code sizes.

• Cost-Effective: Modular structure allows customization based on application requirements.
